2025 TKO Gravel Frame

Regular price
$1,799.00
Sale price
$1,799.00
Regular price
$2,299.00
Sold out
Unit price
per

TKO Titanium Gravel


The TKO is the bike that everyone should have in their stable. Use it as a road bike with skinny tires, throw some fatties on for gravel grinding, or add some bags for touring and adventure riding.  The frame boasts fully internal cable routing, clearance for 55c+ tires (depending on tire and rim combo), UDH/full mount compatible dropouts and IS headset.

All TKO Frames feature the following:

  • Vassago size specific 3AL/2.5V titanium tubing
  • S-Bend seat and chainstays
  • IS 56 internal headset
  • 700x55c tire clearance
  • 142x12mm through-axle UDH Dropouts
  • Internal cable routing options - through headset for ENVE in-route or FSA ACR systems or ritchey switch
  • Internal Dropper post routing with 1x systems
  • Bottom Bracket: T47 internal
  • Seatpost - 30.9 (optional 27.2)
  • Seatpost Clamp - 34.9 (included)
  • Disc Brakes: flatmount 140mm rear
  • Dropouts and Rear Spacing: 142x12mm through axle
  • Ft. Derailleur: 34.9 clamp
  • Rr. Derailleur: standard
  • Rigid Fork: ENVE Adventure Carbon recommended
